3.4 AV Signal Performance
3.4.1 Video / Component Video Input
All tests must be performed under “video standard testing conditions” unless otherwise specified
3.4.2 AV (Composite Video Input)
Video
System NTSC
Amplitude 1.0 V (p-p), negative sync.
Impedance 75 ohm terminated
3.4.3 Component (Y, Pb/Cb, Pr/Cr Input)
Component
System 480i, 480P, 720P, 1080i, 1080P
Y signal amplitude 1.0Vpp (including sync)
Cr, (R-Y) / Cb, (B-Y)
Signal amplitude
±0.35Vpp, 75 ohm
Impedance
75 ohm terminated
Y = 0.299R + 0.587G + 0.114B
(R-Y) = 0.701R + 0.587G + 0.114B
(B-Y) = 0.299R + 0.587G + 0.886B
3.5 Compatible Mode Table
Analog RGB Input Signal Timing
Supported
Resolution
H(KHZ) V(HZ) Standard EDID Assignment
Panel Type
NOTE2
H×V
1366X768 1920X1080
640×480
31.5 60 VESA DMT
Established Timings
YES YES
720×400
31.5 70 VESA DMT
Established Timings
YES
YES
800×600
37.9 60 VESA DMT
Established Timings
YES
YES
800×600
35.1 56 VESA
Established Timings
YES
YES
1024×768
48.4 60 VESA DMT
Established Timings
YES
YES
1280×768
47.4 60 VESA DMT
Detailed Timing
Description 2
YES
YES NOTE3
1280×720
45 60 VESA DMT
Standard Timing
Identification
YES
YES 16:9
1280×800
49.7 60 VESA DMT
Standard Timing
Identification
YES
YES 16:10
1280×800
62.8 75 VESA DMT
Standard Timing
Identification
YES
YES
16:10
Mandatory
1280×960
60 60 VESA DMT
Standard Timing
Identification
YES
YES 4:3
1280×1024
64 60 VESA DMT
Standard Timing
Identification
YES
YES 5:4
1440×900
55.9 60 VESA DMT
Standard Timing
Identification
YES
YES 16:10
1680×1050
65.3 60 VESA DMT
Standard Timing
Identification
NOTE1
YES
16:10
Mandatory
1920×1080
67.5 60 CEA-861
Detailed Timing
Description 1
NO
YES NOTE3
