Sharp LC-32LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
8
HDMI Input Signal Timing:
Supported
Resolution
H(KHZ) V(HZ) Standard
EDID
Assignment
Panel Type
NOTE2
H×V
1366X768 1920X1080
640×480
31.5 60 VESA DMT
Established
Timings
YES
YES
720×400
31.5 70 VESA DMT
Established
Timings
YES
YES
800×600
37.9 60 VESA DMT
Established
Timings
YES
YES
800×600
35.1 56 VESA
Established
Timings
YES
YES
1024×768
48.4 60 VESA DMT
Established
Timings
YES
YES
1280×768
47.4 60 VESA DMT
Detailed Timing
Description 2
YES
YES NOTE3
1280×720
45 60 VESA DMT
Standard Timing
Identification
YES
YES 16:9
1280×800
49.7 60 VESA DMT
Standard Timing
Identification
YES
YES 16:10
1280×800
62.8 75 VESA DMT
Standard Timing
Identification
YES
YES
16:10
Mandatory
1280×960
60 60 VESA DMT
Standard Timing
Identification
YES
YES 4:3
1280×1024
64 60 VESA DMT
Standard Timing
Identification
YES
YES 5:4
1440×900
55.9 60 VESA DMT
Standard Timing
Identification
YES
YES 16:10
1680×1050
65.3 60 VESA DMT
Standard Timing
Identification
NOTE1
YES
16:10
Mandatory
1920×1080
67.5 60 CEA-861
Detailed Timing
Description 1
YES
YES NOTE3

Sharp LC-32LB261U Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Screen Size	31.5 inches, 32 inches
Refresh Rate	60hz
Brightness	180 candela per square meter
Speakers Output	10 watts
USB Ports	1
RF Antenna	yes
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	1
3D	no
Power Consumption	81 kilowatt hours
Depth with Stand	6.5 inches
Height with Stand	18.38 inches
Width with Stand	28.63 inches
Net Weight with Stand	11.3 pounds
Depth without Stand	2.5 inches
Height without Stand	17.13 inches
Net Weight without Stand	10.6 pounds
