32&42&50LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
71
LC-32LB261U
Item Part No. DESCRIPTION Q’ty
1 LCA315HVN05AC92Q0X PANEL 1
2 378G0110567YDQ SPK 2
3 P34T2250ADTZ1T01BA DECO 1
4 P33T070900101C0100 IR LENS 1
5 IRPFCAB4 IR BOARD 1
6 0M1G1030 6 47 CR3
SCREWDECO/PANEL
6
7 X52G18010TV23500HK POWER BOARD MYLAR 1
8 Q02G707105000100XL BOLT 2
9 PLTVEL261XAB9 POWER BOARD 1
10 CBPFE3SKX3 MAIN BOARD 1
11 Q02G708105000100HX BOLT 1
12 0M1G1730 6120
SCREWPOWER BOARD/PANEL
3
13 X15T9644101000GMLH BKT_IO_SIDE 1
14 0M1G1730 8120
SCREWAC SOCKET/PANEL
1
15 X15T964510100000LH BKT_IO_BTM 1
16 0M1G1730 6120
SCREWMAIN BOARD/PANEL
4
17 X15T948510100000BL BKT_STAND_R 1
18 X15T948410100000BL BKT_STAND_L 1
19 0M1G1730 6120
SCREWBKT_STAND/PANEL
4
20 P34T2249ADT01L0100 BASE 1
21 X12G8009 1 FOOT PAD 4
22 X15T964210100000Z1 BKT_BASE_L 1
23 X15T964310100000Z1 BKT_BASE_R 1
24 0Q1G 140 6120
SCREWBKT_BASE/BASE
4
25 0M1G1740 20225 CR3
SCREWBASE/BKT_STAND
4
26 KEPFEXA3 KEY BOARD 1
27 P33T0638ADT01L0100 KEY 1
28 P33T0637ADTZ1T0200 COVER_KEY 1
29 P34T21100GM0HG0100 REAR COVER 1
30 0M1G1030 6 47 CR3
SCREWREAR COVER, AC SOCKET/PANEL
10
31 0Q1G 940 8 47 CR3
SCREWREAR COVER/DECO
2
32 0M1G1030 8 47 CR3
SCREWREAR COVER/KEY COVER
1
33 0M1G1730 8120
SCREWMAIN BOARD/PANEL
1
34 0M1G 130 6 47 CR3
SCREWREAR COVER/ BKT_IO_BTM
1
