Sharp LC-32LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
72
LC-42LB261U
Item Part No. DESCRIPTION Q’ty
1 P34B2152XKF01X0100 BEZEL 1
2 LCA420HVN07ADS2R0X PANEL 1
3 KEPFEXA3 KEY BOARD 1
4 P33T0638ADT01T0100 KEY 1
5 P33T0637ADTZ1T0200 COVER_KEY 1
6 X52G18010TV24700HK POWER BOARD MYLAR 1
7 PLTVDQ341XXPR POWER BOARD 1
8 X15T9644201000GMLH BKT_IO_SIDE 1
9 X15T964510100000LH BKT_IO_BTM 1
10 CBPFE3SKX4 MAIN BOARD 1
11
Q02G707105000100XL
BOLT 3
12 378G0110567YDG SPEAKER 2
13 X15T950920100000AJ BKT_STAND_R 1
14 X15T950910100000AJ BKT_STAND_L 1
15 P34T2254ADTZ1T01BA DECO 1
16 P33T070900101C0100 IR LENS 1
17 IRPFCAB4 IR BOARD 1
18 P34T21350GM06G0100 REAR COVER 1
19 P34T2255ADT01L0100 BASE 1
20 X15T9635101000GMYF BKT_BASE_L 1
21 X15T9634101000GMYF BKT_BASE_R 1
22 X12G711003900000SI FOOT PAD 6

Sharp LC-32LB261U Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Screen Size	31.5 inches, 32 inches
Refresh Rate	60hz
Brightness	180 candela per square meter
Speakers Output	10 watts
USB Ports	1
RF Antenna	yes
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	1
3D	no
Power Consumption	81 kilowatt hours
Depth with Stand	6.5 inches
Height with Stand	18.38 inches
Width with Stand	28.63 inches
Net Weight with Stand	11.3 pounds
Depth without Stand	2.5 inches
Height without Stand	17.13 inches
Net Weight without Stand	10.6 pounds
