Sharp LC-32LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
73
LC-50LB261U
Item Part No. DESCRIPTION Q’ty
1 P34T21110GM0AG0200 REAR COVER 1
2 P34T2252ADTZ1T01BA DECO 1
3 P34T2253ADT01L0100 BASE 1
4 P33T0638ADT01T0100 KEY 1
5 P33T0637ADTZ1T0200 COVER_KEY 1
6 P33T070900101C0100 IR LENS 1
7 X15T9644201000GMLH BKT_IO_SIDE 1
8 X15T964510100000LH BKT_IO_BTM 1
9 X15T965120100000Z1 BKT_STAND_R 1
10 X15T965110100000Z1 BKT_STAND_L 1
11 X15T964810200000BL BKT_BASE_L 1
12 X15T964910200000BL BKT_BASE_R 1
13 X15T899210100000YF BKT_BASE_TOP 1
14 X15T899310100000YF BKT_BASE_DOWN 1
15 X52G180125300000SI MYLAR 1
16 Q02G707105000100XL BOLT 3
17 X12G711003900000SI FOOT PAD 4
18 0M1G1730 6120
SCREW/MB/ BKT_IO /PANEL）
5
19 0M1G1730 6120
SCREW（POWER BOARD/PANEL）
3
20 0M1G1730 8120
SCREW（AC SOCKET/PANEL）
2
21 0M1G1740 10 47 CR3
SCREW（BKT_STAND/PANEL）
6
22 0M1G1030 6 47 CR3
SCREW（DECO/PANEL）
6
23 0M1G1030 6 47 CR3
SCREW（REAR COVER/PANEL）
13
24 0Q1G1030 10 47 CR3
SCREW（REAR COVER/ DECO）
4
25 0M1G1030 8 47 CR3
SCREW（REAR COVER/KEY COVER）
1
26 0M1G 130 6 47 CR3
SCREW（REAR COVER/BKT_IO）
2
27 0Q1G 130 8120
SCREW（BKT_BASE/BASE）
6
28 XM1G176002022500H1
SCREW（BASE/ BKT_STAND）
4
29 CBPFE3SKX5 MAIN BOARD 1
30 PLTVDV751XXPR POWER BOARD 1
31 KEPFEXA3 KEY BOARD 1
32 378G0110567YDG SPEAKER 2
33 LCA500HVN08AC3250X PANEL 1

Sharp LC-32LB261U Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Screen Size	31.5 inches, 32 inches
Refresh Rate	60hz
Brightness	180 candela per square meter
Speakers Output	10 watts
USB Ports	1
RF Antenna	yes
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	1
3D	no
Power Consumption	81 kilowatt hours
Depth with Stand	6.5 inches
Height with Stand	18.38 inches
Width with Stand	28.63 inches
Net Weight with Stand	11.3 pounds
Depth without Stand	2.5 inches
Height without Stand	17.13 inches
Net Weight without Stand	10.6 pounds
