2008-03-14
LC-19LE320, LC-22LE320, LC-26LE320, LC-32LE320, LC-37LE320, LC-42LE320
77
26” TROUBLESHOOTING TABLE
Power unit operation check.
LINE_FILTER_UNIT: YES
POWER_UNIT
YES
YES
YES
YES
YES
Are the power cord and harness in the unit properly connected?
NO
Connect the power cord and harness properly, and turn on the
ower.
Is F901 F902 normal?
NO
LINE_FILTER_UNIT:
Isn't C914, RV901, RV902, L903, L905, C937, C900, C920, etc.
out of order? Moreover, whether the short-circuit with the
circumference circuit is checked.
Is BD901 (+320V) output?
Does the circuit operate normally?
Check circuit around (BD901, Q905, ZD906, IC901, D902 etc ).
NO
Is a voltage of +5.3V applied to pin (12,13) of connector (CN905)?
Does the switching circuit operate normally?
Check circuit around the primary side (T901, ZD906, D902,
D905, Q905, D904, IC901, Q901, ZD904 etc.), the secondary
side (D903, L902, C911 etc.), the DC_DET circuit (IC902,
ZD903, IC903, IC901, etc.), and the protection circuit.
NO
Is a voltage of +24V applied to pin (1,2,3,4,5) of connector
(CN903)?
NO
Does the inverter circuit operate normally?
Check circuit around (D901, L901, C908, Q903, ZD902 etc.), and
the protection circuit.
Is a voltage of +24V applied to pin (9,10) of connector (CN905)?
NO
Does the inverter circuit operate normally?
Check circuit around (D983, C956, FB985, etc.), and the
protection circuit.
Is a voltage of +12V applied to pin (4,5) of connector (CN905)?
NO
Does the inverter circuit operate normally?
Check circuit around (D985, IC905, D907, L904, C927 etc.), and
the protection circuit.
To Next Page
