LC-32LE345T
3 – 3
Attaching the stand
Before attaching (or detaching) the stand, unplug the AC cord from the AC outlet.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from
being damaged.
1
Confirrm the screws supplied with the TV.
Screw driver
Screw
Soft cushion
Screws (
m
4)
(used in step 3)
2
Insert the stand base to the stand post on
the bottom of the TV. (
1
)
3
Insert and tighten the 4 screws into the 4
holes on the bottom of the stand base. (
2
)
NOTE
To detach the stand, perform the steps in reverse order.
CAUTION
Do not attach or detach the stand without holding it.
Doing so can cause the stand to fall, resulting in serious personal injuries as well as damage to the stand.
Stand
