Sharp LC-32LE511E User Manual

104
LC-32LE511
LC-40LE511
LC-40LE531
REF No. PARTS DESCRIPTION *
PRICE
CODE
D18 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D19 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D2 30018574 DIODE SCH SS33 3A/30V DO214AB ROHS G --
D20 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D21 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D22 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D23 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D26 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D28 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D30 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D35 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D38 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D39 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D40 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D41 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D42 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D43 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D45 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D46 30042066 DIODE SMDSCH1N5819 1A/40V/25A SOD123ROHS G --
D47 30038472 DIODE SMD ZEN C5.1V SOD123 ROHS G --
D48 30038472 DIODE SMD ZEN C5.1V SOD123 ROHS G --
D51 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D52 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D55 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D56 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D57 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D59 30049532 DIODE SCH SK24 2A/40V/50A DO214AC ROHS G --
D6 30007169 DIODE DUALBAV99 0.215A/70V 4.5ASOT23ROHS G --
D61 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D7 30007169 DIODE DUALBAV99 0.215A/70V 4.5ASOT23ROHS G --
D8 30007169 DIODE DUALBAV99 0.215A/70V 4.5ASOT23ROHS G --
X1 30040167 XTAL 10MHz 16pF 30ppm 50OhmHC49S SMDROHS G --
X10 30069192 XTAL 54MHZ 19PF 15ppm 15Ohm 3225 SMDROHS G --
X11 30067372 XTAL 41MHZ 9.4pF 20ppm SMD 3.2x2.5 ROHS G --
F100 30001735 RES SMD 1/8W 0R 1206 ROHS G --
F101 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F102 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F111 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F112 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F113 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F114 30039657 FERRIT SMD 220/100MHz 0.3R M 200mA 603Ro G --
F115 30039657 FERRIT SMD 220/100MHz 0.3R M 200mA 603Ro G --
F116 30039657 FERRIT SMD 220/100MHz 0.3R M 200mA 603Ro G --
F117 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F118 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F119 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F120 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F121 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F122 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F123 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F124 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F125 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F126 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
PACKAGED CIRCUITS
COILS AND FILTERS
REF No. PARTS DESCRIPTION *
PRICE
CODE
F127 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F128 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F129 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F130 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F131 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F132 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F133 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F134 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F135 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F136 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F137 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F138 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F139 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F140 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F141 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F142 30012012 FERRIT SMD 75R/100MHz 0.1R M 1A 0805 Ro G --
F162 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F163 30061050 FERRIT SMD 600R/100MHz 3A 0.2R(1206)RoHS G --
F164 30061050 FERRIT SMD 600R/100MHz 3A 0.2R(1206)RoHS G --
F165 30061050 FERRIT SMD 600R/100MHz 3A 0.2R(1206)RoHS G --
F170 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F171 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F172 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F173 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F174 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F175 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F176 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F177 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F178 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F179 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F180 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F181 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F182 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F183 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F187 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F188 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F189 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F19 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F190 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F191 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F194 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F195 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F196 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F197 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F198 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F200 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F201 30031742 FERRIT SMD 120R/100MHz 0R2 M 0.2A 603Ro G --
F202 30031742 FERRIT SMD 120R/100MHz 0R2 M 0.2A 603Ro G --
F203 30031742 FERRIT SMD 120R/100MHz 0R2 M 0.2A 603Ro G --
F21 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F26 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F27 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F28 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F301 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F302 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F304 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
