Sharp LC-32LE511E User Manual

105
LC-32LE511
LC-40LE511
LC-40LE531
LC-32LE511
LC-40LE511
LC-40LE531
REF No. PARTS DESCRIPTION *
PRICE
CODE
F305 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F306 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F307 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F308 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F309 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F31 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F310 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F32 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F324 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F325 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F33 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F34 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F35 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F36 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F38 30001735 RES SMD 1/8W 0R 1206 ROHS G --
F42 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F43 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F44 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F51 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F54 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F56 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F6 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F62 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F65 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F67 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F68 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F69 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F7 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F70 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F71 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F72 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F74 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F75 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F76 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F77 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F78 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F79 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F80 30025444 FERRIT SMD 1K/100MHz 0.7R M 100mA 603Roh G --
F81 30025444 FERRIT SMD 1K/100MHz 0.7R M 100mA 603Roh G --
F82 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F83 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F86 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F87 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F88 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F89 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F90 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F91 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F92 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F93 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F94 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F95 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F96 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F97 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
L10 30069761 COIL SMD 22uH 1.6A M 0.4R 8.3x9x3(SHL)Ro G --
L11 30069761 COIL SMD 22uH 1.6A M 0.4R 8.3x9x3(SHL)Ro G --
L12 30069761 COIL SMD 22uH 1.6A M 0.4R 8.3x9x3(SHL)Ro G --
REF No. PARTS DESCRIPTION *
PRICE
CODE
L13 30062560 COIL SMD 2.2UH 7A M 0R01 12x12(SHL)Ro G --
L2 30016659 COIL SMD 1uH 50mA K 0R4 805 Ro G --
L3 30016659 COIL SMD 1uH 50mA K 0R4 805 Ro G --
L32 30061408 COIL SMD 4.7uH 2.4A M 54R 7x7(SHL)Ro G --
L33 30061048 COIL SMD 15uH 4.5A M 27R 12x12(SHL)Ro G --
L34 30057443 COIL SMD 1.2uH 4.3A M 0R025 5x5.2SHL)Ro G --
L35 30057443 COIL SMD 1.2uH 4.3A M 0R025 5x5.2SHL)Ro G --
L4 30016659 COIL SMD 1uH 50mA K 0R4 805 Ro G --
L42 30053396 COIL SMD 220nH 0.12A G 2R5 603 Ro G --
L5 30070927 COIL SMD 330nH 0A25 K 0R55 MB70 805 Ro G --
L6 30070927 COIL SMD 330nH 0A25 K 0R55 MB70 805 Ro G --
L7 30057443 COIL SMD 1.2uH 4.3A M 0R025 5x5.2SHL)Ro G --
L8 30057443 COIL SMD 1.2uH 4.3A M 0R025 5x5.2SHL)Ro G --
L9 30069761 COIL SMD 22uH 1.6A M 0.4R 8.3x9x3(SHL)Ro G --
TU1 30068457 TUNER HYRID HALF-NIM FT2112 RoHS G --
C10 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C100 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C101 30022334 CAP SMD 2.2NF 50V J X7R (0402) ROHS G --
C102 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C103 30022334 CAP SMD 2.2NF 50V J X7R (0402) ROHS G --
C104 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C105 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C106 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C107 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C11 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C110 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C111 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C116 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C117 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C118 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C12 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C13 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C137 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C138 30064783 CAP SMD 1UF 6.3V K X6S (0402) ROHS G --
C139 30064783 CAP SMD 1UF 6.3V K X6S (0402) ROHS G --
C14 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C140 30064783 CAP SMD 1UF 6.3V K X6S (0402) ROHS G --
C141 30064783 CAP SMD 1UF 6.3V K X6S (0402) ROHS G --
C148 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C149 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C15 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C150 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C151 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C16 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C161 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C163 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C164 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C165 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C166 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C167 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C168 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C169 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C17 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
TUNER
CAPACITORS
