Sharp LC-32M400M-BK - Disconnecting Internal Connectors

LC-32M400M-BK/WH/RD
4 – 2
2. Disconnect the connectors
1. Disconnect the connectors from the MAIN Unit, IR/OPC Unit, POWER, Unit, TERMINAL Unit, INVERTER Unit and LCD Panel Module [1].
MAIN Unit
INVERTER Unit
1
1
AC
LVDS
LVDS
SP
MA MB
MA MB
SP
P0
VA/VB
VA/VB
PW
SP
RA
RA
POWER Unit
IR/OPC Unit
1
1
LCD Panel Module
