PARTS GUIDE
No. S51Q1LC32M40M
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32M400M-BK/WH/RD
MODELS
LC-32M400M-BK
LC-32M400M-WH
LC-32M400M-RD
LCD COLOUR TELEVISION
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] DKEYMF878FM01/FM02 (MAIN
Unit)
[4] DUNTKF879WE01 (IR/OPC Unit)
[5] DUNTKF885FM01 (TERMINAL
Unit)
[6] CABINET AND MECHANICAL
PARTS
[7] SUPPLIED ACCESSORIES
[8] PACKING PARTS (NOT
REPLACEMENT ITEM)
[9] SERVICE JIGS (USE FOR
SERVICING)
INDEX
