Sharp LC-32PX5M User Manual

LC-32PX5M/X/LC-37PX5M/X
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET PARTS (LC-32PX5M/X)
1 CCABAB613WJ03 BR S V Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 GCOVAC066WJ4A N V Front Cover
1-3 Not Available - - Badge, "SHARP"
1-4 HDECQA684WJSA V Decoration Cover
1-5 HDECSA005WJKA AN V Shine Trim
1-6 HPNLSA098WJSA AX V Speaker Sheet
1-7 PSPAHB079WJZZ AE V Spacer (Top, Bottom), x2
1-8 PSPAHB080WJZZ AD V Spacer (Side), x2
1-9 PSPAHB085WJZZ AB V Spacer (LED Cover), x2
1-10 PSPAZB264WJZZ AD V Spacer, x6
1-11 XEBS930P08000 AA J Screw, x4
2 CCABBA998WJ01 BH S V Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPC167WJ4A AH S V Terminal Label
2-3 PSPAHB074WJZZ AB V Spacer, x2
2-4 PSPAHB146WJ4Z AC N V Spacer, x2
2-5 PSPAHB147WJ4Z AD N V Spacer, x2
2-6 PSPAHB148WJ4Z AD N V Spacer
2-7 PSPAHB149WJ4Z AB N V Spacer
2-8 PSPAHB150WJ4Z AB N V Spacer, x2
2-9 PSPAHB151WJ4Z AB N V Spacer
3 CCOVAC064WJ01 AN N V Top Cover Ass'y
3-1 Not Available - N - Top Cover
3-2 JBTN-A645WJ4A AE N V Power Bottom
3-3 JBTN-A646WJ4A AG N V Operate Bottom
3-4 MSPRCA070WJ2J AB J Spring
3-5 PSPAHB152WJ4Z AB N V Spacer
5 DUNTKD892FM50 BV N V Main Unit (LC-32PX5M)
5 DUNTKD892FM51 BV N V Main Unit (LC-32PX5X)
6 DUNTKD893FM50 BT N V Tuner/Av Unit (LC-32PX5M)
6 DUNTKD893FM51 BT N V Tuner/Av Unit (LC-32PX5X)
7 DUNTKE095FM02 AQ N V LED, R/C Unit
8 DUNTKE097FM02 AN N V
Operation Unit
9 GCOVAB731WJSA AS J AV Terminal Cover
10 GCOVAB736WJKA AD J Bus Cover, x2
11 GCOVAB937WJ4A AH V Stand Area Cover
12 HINDPC148WJSA AE N V Model Label (LC-32PX5M)
12 HINDPC147WJSA AE N V Model Label (LC-32PX5X)
13 LANGKA638WJFW AL V LCD Angle A, x2
14 LANGKA672WJFW AF V LCD Angle C
15 LANGKA792WJFW AG J Pwb Bracket B
16 LANGKA908WJFW AH V Support Angle
17 LANGKA934WJFW AR V Sus Angle (L)
18 LANGKA985WJFW AS S V Sus Angle (R)
19 LANGKB020WJFW AL N V LCD Angle B, x2
20 LANGTA413WJFW AU V Stand Angle
21 LCHSMA369WJZZ BB S V Chassis Tray
22 LHLDFA028WJKZ AC J Wire Holder A
23 LHLDWA120WJKZ AB J Wire Holder B, x2
24 LHLDWA134WJKZ AB J Wire Holder C
25 LX-HZA003WJFN AC J Screw, x2
26 PSPAGA344WJZZ AC N J Spacer, x4
27 PSPAHA702WJZZ AB N V Spacer
28 PSPAZB366WJZZ AE N V Rubber Spacer, x2
29 QCNW-E756WJQZ AH N V Connecting Cord (SH)
30 QCNW-E758WJQZ AL N V Connecting Cord (LA)
31 QCNW-E759WJQZ AL J Connecting Cord (PE)
32 QCNW-E760WJQZ AK J Connecting Cord (PD)
33 QCNW-E762WJQZ AP J Connecting Cord (RA)
34 QCNW-E764WJQZ AK N V Connecting Cord (SP)
35 QCNW-F068WJPZ AZ N V Connecting Cord (LV)
36 R1LK315T3LZ4BX EE N V 32" LCD Panel Module Unit
37 RDENCA182WJQZ BS N V Power Unit
38 RSP-ZA203WJZZ BB V Speaker (L)
39 RSP-ZA204WJZZ BB V Speaker (R)
40 TLABNB947WJZZ AB N V No Label (LC-32PX5M)
40
TLABNB946WJZZ AB N V No Label (LC-32PX5X)
41 XBBS830P08000 AA J Screw, x4
42 XBPS730P06WS0 AA J Screw, x43
43 XBPS830P06000 AA J Screw, x2
44 XEBS930P08000 AA J Screw, x3
45 XEBS930P10000 AA J Screw, x5
46 XEBS930P16000 AB J Screw, x2
47 XEBS940P16000 AB J Screw, x19
48 QCNW-F546WJQZ V Connecting Cord (KM)
