NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[5] CABINET PARTS (LC-37PX5M/X)
1 CCABAB582WJ04 BU S V Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 GCOVAC065WJ4A N V Front Cover
1-3 Not Available - - Badge, "SHARP"
1-4 HDECQA667WJSA V Decoration Cover
1-5 HDECSA004WJKA AP V Shine Trim
1-6 HPNLSA097WJSA AX V Speaker Sheet
1-7 PSPAHA933WJZZ AE V Spacer (Top, Bottom)
1-8 PSPAHA934WJZZ AD V Spacer (Side)
1-9 PSPAHB085WJZZ AB V Spacer (LED Cover), x2
1-10 PSPAZB264WJZZ AD V Spacer, x6
1-11 XEBS930P08000 AA J Screw, x4
2 CCABBA999WJ01 BK S V Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPC167WJ4A AH N V Terminal Label
2-3 PSPAHB149WJ4Z AB N V Spacer
2-4 PSPAHB153WJ4Z AC N V Spacer
2-5 PSPAHB154WJ4Z AD N V Spacer
2-6 PSPAHB155WJ4Z AD N V Spacer
3 CCOVAC064WJ01 AN S V Top Cover Ass'y
3-1 Not Available - N - Top Cover
3-2 JBTN-A645WJ4A AE N V Power Bottom
3-3 JBTN-A646WJ4A AG N V Operate Bottom
3-4 MSPRCA070WJ2J AB J Spring
3-5 PSPAHB152WJ4Z AB N V Spacer
5 DUNTKD892FM52 BV N V Main Unit (LC-37PX5M)
5 DUNTKD892FM53 BV N V Main Unit (LC-37PX5X)
6 DUNTKD893FM52 BT N V Tuner/Av Unit (LC-37PX5M)
6 DUNTKD893FM53 BT N V Tuner/Av Unit (LC-37PX5X)
7 DUNTKD897FM53 AQ N V LED, R/C Unit
8 DUNTKE097FM04 AN N V Operation Unit
9 GCOVAB738WJSA AS J AV Terminal Cover
10 GCOVAB736WJKA AD S J Bus Cover, x2
11 GCOVAB907WJ4A AK S V
Stand Area Cover
12 HINDPC150WJSA AE N V Model Label (LC-37PX5M)
12 HINDPC146WJSA AE N V Model Label (LC-37PX5X)
13 LANGFA330WJFW AL V Support Angle
14 LANGKA792WJFW AG J Pwb Bracket B
15 LANGKA939WJFW AK V LCD Angle L
16 LANGKB021WJFW AK N V LCD Angle R
17 LANGKB025WJFW AM N V LCD Angle Center, x2
18 LANGTA403WJFW AV V Center Angle, x2
19 LANGTA421WJFW AT V Stand Angle
20 LCHSMA369WJZZ BB S V Chassis Tray
21 LHLDFA028WJKZ AC J Wire Holder A
22 LHLDWA120WJKZ AB J Wire Holder B, x2
23 LHLDWA134WJKZ AB J Wire Holder C
24 LX-HZA003WJFN AC J Screw, x4
25 PSPAGA344WJZZ AC S J Spacer, x4
26 PSPAHB156WJ4Z AB N V Spacer
27 PSPAZB366WJZZ AE S V Rubber Spacer, x2
28 QCNW-E752WJQZ AP J Connecting Cord (RA)
29 QCNW-E756WJQZ AH N V Connecting Cord (SH)
30 QCNW-E758WJQZ AL N V Connecting Cord (CN1)
31 QCNW-E759WJQZ AL N V Connecting Cord (PE)
32 QCNW-E760WJQZ AK N V Connecting Cord (PD)
33 QCNW-F068WJPZ AZ N V Connecting Cord (LV)
34 QCNW-F613WJQZ AK N V Connecting Cord (SP)
35 R1LK370T3LZ5BX EZ N V 37" LCD Panel Module Unit
36 RDENCA182WJQZ BS N V Power Unit
37 RSP-ZA203WJZZ BB V Speaker (L)
38 RSP-ZA204WJZZ BB V Speaker (R)
39 TLABNB949WJZZ AB N V No Label (LC-37PX5M)
39 TLABNB945WJZZ AB N V No Label (LC-37PX5X)
40 XBBS740P06000 AA J Screw, x4
41 XBBS830P08000 AA J Screw, x6
42 XBPS730P06WS0 AA J Screw, x43
43
XBPS830P06000 AA J Screw, x2
44 XEBS930P08000 AA J Screw
45 XEBS930P10000 AA J Screw, x13
46 XEBS930P16000 AB J Screw, x2
47 XEBS940P16000 AB J Screw, x13
48 QCNW-F564WJQZ V Connecting Cord (KM)
