LC-32R24B
2 – 4
10.Remove the 1 lock screw and detach the Bottom Cover.
11.Remove the 4 lock screws and detach the Stand Fix Angle.
12.Remove the R/C, LED Unit.
11
12
10
Stand Fix Angle
R/C, LED Unit
Bottom Cover
