LC-32R24B
3 – 14
9. White balance adjustment
9.1. White balance adjustment
Adjustment item Adjustment conditions Adjustment procedure
1 Adjustment Detail of adjustment method refer to [KAMEYAMA models monitor WB adjustment spec
V1.9].
1) Setting the set with below condition.
AV MODE : [DYNAMIC]
Backlight : +16
Aging Time : Min. 60 minutes
2) Connect the white balance jigs with set.
2 Auto adjustment
Performance
[Command]
Service mode
KRSW0001
KKT10037
Setting
KYOF0000
OSDS0001
SBSL0016
Multi-points adjust mode
MSET0001
HIGH point
WBIH0832
MGHG****
MGHB****
MGHR****
LOW point
WBIL0176
MGLG****
MGLB****
MGLR****
[Adjustment Method]
1) Press R/C to enter [monitor adjustment] code.
2) Set the HIGH point to the appointed steps, decide the strongest color as fixed color,
decrease to become reference value by adjusting the RGB.
3) Set the LOW point to the appointed steps, set the correction value of G (176 x HIGH
point G value/832) and adjust RB to the nearest reference value.
4) Use MSET0002 command, input the adjusted value and off the AC power.
* Initial value at each point: setting steps level.
[Adjusted value]
•Based on teaching set [LC-32R24B] as [standard setting] submitted by Eng Depart-
ment.
[Reference value]
Machine: Minolta CA-210 analyzer
Level Ref Value Spec Inspect Spec
WRITE
HIGH 832
x = 0.272
±0.0010 ±0.0020
MSET0002 y = 0.277
LOW 176
x = 0.272
±0.0020 ±0.0030
y = 0.277
Remark LCDTV condition
AV MODE: [DYNAMIC] (Reset)
Active Contrast: OFF
Color Temp: HIGH
Back Light: +16
Aging Time: 60 minutes
