LC-32R24B
4 – 12
No audio (4)
INPUT-4 No audio (HDMI connected)
INPUT-5 No audio (HDMI connected)
[INPUT-4 input]
Is INPUT-4 selected on the input select menu screen?
[INPUT-5 input]
Is INPUT-5 selected on the input select menu screen?
YES
NO
Is the audio output selected for “VARIABLE” on the
menu screen?
Set the audio output to “FIXED”.
[INPUT-4 input] If no video appears, refer to “No external input video
(HDMI) [INPUT-4]”.
[INPUT-5 input] If no video appears, refer to “No external input video
(HDMI) [INPUT-5]”.
YES
Is the HDMI MUTE line as specified?
YES
NO
Check Q1301, IC1302 and their peripheral circuits.
Does the audio signal come from pins (AN28) (SPOUT_LP), (AN29)
(SPOUT_RN), (AP28) (SPOUT_LN), and (AP29) (SPOUT_RP) of
IC8001 to pins (5) (SP_LP), (6) (SP_LN), (8) (SP_RN), and (9)
(SP_RP) of IC2701 (AMP)?
NO
Check the line between IC8001 and IC2701, and their
peripheral circuits. (AMP_MUTE line, etc.)
YES
Is the audio output from IC2701 as specified? NO Check IC2701 and its peripheral circuits.
YES
Check the connector (P2701), speakers and their peripheral circuits.
