Sharp LC-37D44U - PARTS GUIDE; Printed Wiring Board Assemblies and Panels; Unit Assemblies (R;C, LED, KEY, MAIN); Cabinet and Mechanical Parts

PARTS GUIDE
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-37D44U
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
No. S18D7LC37D44U
LC-37D44U
MODEL
PartsGuide
[1] PRINTED WIRING BOARD ASSEMBLIES
[2] LCD PANEL (NOTE: THE PARTS HERE
SHOWN ARE SUPPLIED AS AN ASSEMBLY
BUT NOT INDEPENDENTLY.)
[3] DUNTKE264FM02 (R/C, LED Unit)
[4] DUNTKE266FM02 (KEY Unit)
[5] DUNTKE450FM01 (MAIN Unit)
[6] NOTE (Conductive cloth tape/Gasket)
[7] CABINET AND MECHANICAL PARTS
[8] SUPPLIED ACCESSORIES
[9] PACKING PARTS (NOT REPLACEMENT ITEM)
[10] SERVICE JIG (USE FOR SERVICING)
