Sharp LC-37D44U - CHAPTER 4. REMOVING OF MAJOR PARTS; Procedure for Major Part Removal

LC-37D44U
4 – 1
LC-37D44U
Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Remove the 4 lock screws and detach the Stand.
2. Remove the 1 lock screw, 4 lock screws, 6 lock screws and detach the Rear Cabinet.
2
2
2
1
Front Cabinet
Rear Cabinet
Stand
