2. SPECIFICATIONS
LC-32CHG6242E
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, DTS TruSurround and DTS 2.0+Digital Out are trademarks of DTS, Inc. © DTS, Inc. All Rights Reserved.
www.sharp.eu/av
DISPLAY
Diagonal screen size cm / inch 81/32
Panel resolution 1366x768
Active motion 200
Backlight D-LED
Brightness (cd/m²) 300
Dynamic contrast 1 000 000:1
AUDIO SYSTEM
Speaker Full-range + silk tweeter
Speaker Power 2x10W (8 ohm)
Sound Technology Harman-Kardon
Sound System B/G, D/K, I, L
NICAM/A2
Sound Settings Sound Equalizer
Audio decoder Dolby Digital/Digital+
Audio enhancement solution DTS TruSurround HD™
TUNER
TV system ATV PAL, SECAM
DTV DVB-T/T2/C/S/S2
(MPEG4 + HEVC/H.265)
FUNCTION
SHARP AQUOS NET+ Apps store YES
Pre-install Apps YouTube, Deezer, Netix,
Web browser and many more
Hbb TV YES
DLNA media player
for Video / Photo / Music YES / YES / YES
Miracast YES
PC wireless connection YES
WiFi YES
USB Video AVI/MKV/WMV/ASF/MP4/M4v/RM/
RMVB/VOB/TS/M2TS/MPG/FLV/SWF
Video Codec HEVC/H.265, MPEG4/H.264, VP9
USB Music MP3, M4a, WMA, AAC, AC3, EAC3,
LPCM, OGG
USB Photo JPG, JPEG, BMP, PNG
PVR Ready with timeshift YES (FAT32 only)
USB Software Update YES
USB le system FAT16/FAT32/NTFS
HDMI-CEC YES
HDMI-ARC YES (HDMI2)
MHL YES (HDMI3)
OAD YES
Digital Program List YES
Hotel Mode YES
CONNECTORS
HDMI-in YES (3x)
USB YES (2x)
RJ 45 (LAN) YES
SCART YES
Common interface / CI+ YES
Antenna In (RF) YES
Sat In YES
Mini Component/YPbPr YES
Mini AV Composite input + Audio In YES
PC Input (D-sub15 pin) YES
PC Audio Input YES
Audio out / Headphone Jack YES
Digital Optical Audio Output YES
HOTEL MODE
Source Lock YES
Default source YES
Default Program YES
Default Volume YES
Max Volume YES
Import USB YES
Export USB YES
OTHERS
Power Requirements 220-240V / 50Hz
Safety Logo Certication CE (EMC), CB (Safety),
ErP (Energy) etc
ErP Compliant A+ Class
Power Consumption
(ecomode/standard/max) 31/45/70W
Power Consumption (Standby Mode) <0.50 W
VESA standard (mm) 400 x 200
EAN 4974019906805
Net size with stand (W x H x D in mm): 728,3 x 461,3 x 168,0
Net size without stand (W x H x D in mm): 728,3 x 425,9 x 68,3
Box size (W x H x D in mm): 797 x 127 x 508
Net weight with stand (kg) 4,8
Brutto weight (kg) 6,4
PVR is not available in DACH-region
The LC-32CHG6242E is an HD Ready Smart D-LED TV
with exceptional picture quality.
Whether using the integrated Smart TV functions or connecting to your smart device, it’s simple and fun.
With 3 HDMI ports, you can connect to your Satellite box, games console, Blu-Ray player or any other HDMI
equipped device. Its USB port allows you to enjoy your music, movies or photos from a USB memory key.
Product Fiche
Supplier trademark Sharp LC-32CHG6242E
Energy class A+
Screen size 81 cm / 32 inches
Power consumption 31.0 W
Annual energy consumption* 45 kWh
Standby power consumption <0.50 W
Not applicable
Screen resolution 1366 (H) × 768 (V)
* - Energy consumption XYZ kWh per year, based on the power consumption
of the television operating 4 hours per day for 365 days. The actual energy
consumption will depend on how television is used.
Sharp believe that seeing is believing /This is Why our
latest LED TVs feature innovative technologies for the most
vibrant, colourful picture yet.
LC-32CHG6242E
SCREEN SIZE 81 cm (32”)
HD TUNER DVB-T/T2/C/S/S2
3 HDMI INPUTS
USB FOR MULTIMEDIA
PLAYBACK AND RECORDING
SMART TV
200
Wireless
Connection
H.265
HEVC
ACE PRO
PC VGA

Sharp LC-40CFG6452E Specifications

General

Desktop stand	Yes
Video apps	Netflix, YouTube
Operating system installed	-
Product color	Black, Silver
Panel mounting interface	400 x 200 mm
Screen shape	Flat
Display diagonal	40 \
Display brightness	300 cd/m²
Display technology	LED
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Display diagonal (metric)	102 cm
Motion interpolation technology	AMR (Active Motion Rate) 400
3D	No
Annual energy consumption	66 kWh
Number of batteries supported	2
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	80 W
Power consumption (standby)	0.5 W
Power consumption (typical)	45 W
Package depth	632 mm
Package width	964 mm
Package height	114 mm
Package weight	10500 g
Sustainability certificates	RoHS
Audio decoders	Dolby Digital, DTS TruSurround
RMS rated power	20 W
Tuner type	Analog & digital
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
Audio formats supported	AAC, AC3, EAC3, LPCM, M4A, MP3, OGG, WMA
Image formats supported	BMP, JPEG, JPG, PNG
Video formats supported	ASF, AVI, FLV, H.264, H.265, HEVC, M2TS, M4V, MKV, MP4, MPEG4, MPG, RM, RMVB, SWF, TS, VOB, VP9, WMV
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth (with stand)	202 mm
Height (with stand)	569.1 mm
Weight (with stand)	7700 g
Depth (without stand)	67.1 mm
Width (without stand)	916.8 mm
Height (without stand)	546.5 mm
Weight (without stand)	- g
