Sharp LC-40LE510E Service Manual

113
LC-32LE510
LC-40LE510
REF No. PARTS DESCRIPTION *
PRICE
CODE
R428 30007026 RES SMD 1/10W 5.1K J 0805 ROHS G --
R429 30007026 RES SMD 1/10W 5.1K J 0805 ROHS G --
! F100 30028356 FUSE SAFE 3.15A 250V (RADIAL) ROHS G --
! F101 30028356 FUSE SAFE 3.15A 250V (RADIAL) ROHS G --
F200 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J103 30002583 JUMPER WIRE 0.6MM G --
J104 30002583 JUMPER WIRE 0.6MM G --
J105 30002583 JUMPER WIRE 0.6MM G --
J107 30002583 JUMPER WIRE 0.6MM G --
J108 30002583 JUMPER WIRE 0.6MM G --
J110 30002583 JUMPER WIRE 0.6MM G --
J111 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J113 30002583 JUMPER WIRE 0.6MM G --
J114 30002583 JUMPER WIRE 0.6MM G --
J115 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J116 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J118 30002583 JUMPER WIRE 0.6MM G --
J119 30002583 JUMPER WIRE 0.6MM G --
J120 30002583 JUMPER WIRE 0.6MM G --
J121 30002583 JUMPER WIRE 0.6MM G --
J122 30002583 JUMPER WIRE 0.6MM G --
J124 30002583 JUMPER WIRE 0.6MM G --
J125 30002583 JUMPER WIRE 0.6MM G --
J126 30002583 JUMPER WIRE 0.6MM G --
J127 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J129 30002583 JUMPER WIRE 0.6MM G --
J130 30002583 JUMPER WIRE 0.6MM G --
J132 30002583 JUMPER WIRE 0.6MM G --
J133 30002583 JUMPER WIRE 0.6MM G --
J134 30002583 JUMPER WIRE 0.6MM G --
J136 30002583 JUMPER WIRE 0.6MM G --
J137 30002583 JUMPER WIRE 0.6MM G --
J138 30002583 JUMPER WIRE 0.6MM G --
J139 30002583 JUMPER WIRE 0.6MM G --
J140 30002583 JUMPER WIRE 0.6MM G --
J141 30002583 JUMPER WIRE 0.6MM G --
J143 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J144 30002583 JUMPER WIRE 0.6MM G --
J145 30002583 JUMPER WIRE 0.6MM G --
J146 30002583 JUMPER WIRE 0.6MM G --
J147 30002583 JUMPER WIRE 0.6MM G --
J149 30002583 JUMPER WIRE 0.6MM G --
J150 30002583 JUMPER WIRE 0.6MM G --
J153 30002583 JUMPER WIRE 0.6MM G --
J154 30002583 JUMPER WIRE 0.6MM G --
J155 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J156 30002583 JUMPER WIRE 0.6MM G --
J157 30002583 JUMPER WIRE 0.6MM G --
J158 30002583 JUMPER WIRE 0.6MM G --
J159 30002583 JUMPER WIRE 0.6MM G --
J160 30002583 JUMPER WIRE 0.6MM G --
J161 30002583 JUMPER WIRE 0.6MM G --
MISCELLANEOUS PARTS
REF No. PARTS DESCRIPTION *
PRICE
CODE
J162 30002583 JUMPER WIRE 0.6MM G --
J163 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J164 30002583 JUMPER WIRE 0.6MM G --
J166 30002583 JUMPER WIRE 0.6MM G --
J167 30002583 JUMPER WIRE 0.6MM G --
J169 30002583 JUMPER WIRE 0.6MM G --
J170 30002583 JUMPER WIRE 0.6MM G --
J174 30002583 JUMPER WIRE 0.6MM G --
J175 30002583 JUMPER WIRE 0.6MM G --
J176 30002583 JUMPER WIRE 0.6MM G --
J179 30001735 RES SMD 1/8W 0R 1206 ROHS G --
J180 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J181 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J182 30002583 JUMPER WIRE 0.6MM G --
J183 30001734 RES SMD 1/10W 0R 0805 ROHS G --
J187 30001734 RES SMD 1/10W 0R 0805 ROHS G --
MD101 35027467 GROUND TERMINAL 4 MM GND-8 ROHS G --
MD102 35027587 GROUND TERMINAL 5 MM GND-20 ROHS G --
MD103 35027587 GROUND TERMINAL 5 MM GND-20 ROHS G --
MD200 35027467 GROUND TERMINAL 4 MM GND-8 ROHS G --
PG3 40045272 SPACER SUPPORT DCBS-8 RoHS V0 G --
PG4 40045272 SPACER SUPPORT DCBS-8 RoHS V0 G --
!
PL100 30070259 CONNHEADERSAFE 2PV0 7.92 R/A 3.5mmBLKRHS G --
! PL100- 35000176 EYELET BR 2*3MM ROHS G --
! PL101 30070232 CONNHEADER SAFE 2P V0 7.92SIDE 3.5mm RHS G --
! PL101- 35000176 EYELET BR 2*3MM ROHS G --
PL205 30067935 CONN HEADER 2X14P 2.54 W/LOCK SIDE RoHS G --
PL306 30048870 CONN HEADER 12P 2.5MM SIDE WHT ROHS G --
S104 30002583 JUMPER WIRE 0.6MM G --
S117 30002583 JUMPER WIRE 0.6MM G --
S202 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S207 30002583 JUMPER WIRE 0.6MM G --
S208 30002583 JUMPER WIRE 0.6MM G --
S300 30001735 RES SMD 1/8W 0R 1206 ROHS G --
S301 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S303 30001734 RES SMD 1/10W 0R 0805 ROHS G --
S304 30001734 RES SMD 1/10W 0R 0805 ROHS G --
TH103 30067963 RES THE SAFE 10R/2.3A NTC 7mm RoHS G --
TH105 30067963 RES THE SAFE 10R/2.3A NTC 7mm RoHS G --
! TR100 30068375 TRF PFC SAFE 250uH PQ35 10mm PW0426/32R G --
! TR100- 35000176 EYELET BR 2*3MM ROHS G --
! TR101 30068003 Choke Coil 150uH 3A K 20x20x10.5 RoHS G --
!
TR200 30068583 TRF SMT SAFE RES PW04 EEM4344 10mmDRIN R G --
! TR300 30068115 TRF SMT SAFE 42''Slim EPC19 St-By 10mmRo G --
IC100 30053502 IC PFC FAN7529 SO8 ROHS G --
! IC200 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
! IC201 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC202 30065433 IC PFM CONT FAN7621 SOP16 RoHS G --
! IC300 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC301 30063524 IC STAND-BY FSQ211 DIP8 ROHS G --
LC-40LE510-POWER SUPPLY
INTEGRATED CIRCUITS
17PW07
