Sharp LC-40LE510E Service Manual

114
LC-32LE510
LC-40LE510
REF No. PARTS DESCRIPTION *
PRICE
CODE
! IC302 30015087 IC SAFE OPTOCOUPLER TCET1102G G --
IC400 30067808 IC PWM CONT NCP1579 SO8 ROHS G --
IC401 30066849 TR DNMOS FDS8984 7A/30V SO8 RoHS G --
IC402 30067808 IC PWM CONT NCP1579 SO8 ROHS G --
IC403 30066849 TR DNMOS FDS8984 7A/30V SO8 RoHS G --
Q100 30060725 TR NMOS STP9NK50ZFP 7.2A/500V TO220FROHS G --
Q102 30068728 TR NMOS FQT1N60C 0.2A/600V SOT223 ROHS G --
Q200 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q201 30060725 TR NMOS STP9NK50ZFP 7.2A/500V TO220FROHS G --
Q202 30060725 TR NMOS STP9NK50ZFP 7.2A/500V TO220FROHS G --
Q209 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q210 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q211 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q212 30029322 TR NMOS FDV303N 0.68A/25V SOT23 ROHS G --
Q213 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q300 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q301 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q302 30001452 TR PBJT BC327 0.5A/45V TO92 ROHS G --
Q303 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q304 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
D102 30057252 DIODE SMD RS1002FL 0.5A/200V SOD123FL RO G --
D105 30036849 DIODE BRIDGE GBU8K 8A/800V 150A ROHS G --
D106 30001319 DIODE RL207 2A/1000V 70A DO-15 ROHS G --
D107 30051096 DIODE SMD ZEN C6.2V SOD123 ROHS G --
D109 30001319 DIODE RL207 2A/1000V 70A DO-15 ROHS G --
D111 30014352 DIODE MUR460 4A/600V DO-27 ROHS G --
D112 30001319 DIODE RL207 2A/1000V 70A DO-15 ROHS G --
D119 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D150 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D200 30008996 IC VREF TL431SAMF2 ADJ %1 SOT23 ROHS G --
D201 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D202 30038481 DIODE SMD ZEN C6.8V SOD123 ROHS G --
D203 30038498 DIODE SMD ZEN C18V SOD123 ROHS G --
D204 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D206 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D207 30038495 DIODE SMD ZEN C22V SOD123 ROHS G --
D208 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D209 30019996 DIODE BAV70 215mA/75V 4A SOT23 RoHS G --
D210 30038497 DIODE SMD ZEN C3.9V SOD123 ROHS G --
D213 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D214 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D215 30066697 DIODE SCH SR110 1A/100V/30A DO41 ROHS G --
D218 30048782 DIODE SCH STPS20H100CFP20A/100V TO220ROH G --
D219 30001291 DIODE HER107 1A/800V 30A DO41 ROHS G --
D220 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D222 30039202 DIODE SCH STPS2045CFP 20A/45V TO220 ROHS G --
D228 30066697 DIODE SCH SR110 1A/100V/30A DO41 ROHS G --
D238 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D239 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D300 30057252 DIODE SMD RS1002FL 0.5A/200V SOD123FL RO G --
D301 30008996 IC VREF TL431SAMF2 ADJ %1 SOT23 ROHS G --
TRANSISTORS
DIODES
REF No. PARTS DESCRIPTION *
PRICE
CODE
D302 30059220 DIODE SMD RS1008FL 0.5A/800V SOD123FL RO G --
D303 30038498 DIODE SMD ZEN C18V SOD123 ROHS G --
D304 30057252 DIODE SMD RS1002FL 0.5A/200V SOD123FL RO G --
D305 30001345 DIODE ZEN 6.8V 0.5W SOD27 ROHS G --
D308 30066697 DIODE SCH SR110 1A/100V/30A DO41 ROHS G --
D309 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D401 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D404 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
FR100 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR101 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR400 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
FR401 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
FR402 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
FR403 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR404 30006712 FERRIT BEAD AXI 70/100M 3A 3.5x4.7Roh G --
FR405 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
! L101 30069003 LINE FILTER SAFE 2*11mH 1A 0R17 10mm ROH G --
! L102 30069003 LINE FILTER SAFE 2*11mH 1A 0R17 10mm ROH G --
L104 30066913 Ferrite Bead (FTZ) Axial 8x17x7 RoHS G --
L105 30066913 Ferrite Bead (FTZ) Axial 8x17x7 RoHS G --
L201 30067937 Choke Coil 1uH 5A Axial M 0.7R 10x5.5 Ro G --
L202 30067937 Choke Coil 1uH 5A Axial M 0.7R 10x5.5 Ro G --
L205 30001735 RES SMD 1/8W 0R 1206 ROHS G --
L300 30067937 Choke Coil 1uH 5A Axial M 0.7R 10x5.5 Ro G --
L302 30024779 FERRIT SMD 50R/100MHZ 0.4R M 3A 1206 ROH G --
L306 30002016 COIL AXI 150UH 85MA K 15R 2.7X7 RO G --
L401 30062563 Choke coil Toroid Safe 33uH 3A K 6x12Ro G --
L402 30001735 RES SMD 1/8W 0R 1206 ROHS G --
L413 30062563 Choke coil Toroid Safe 33uH 3A K 6x12Ro G --
L414 30001735 RES SMD 1/8W 0R 1206 ROHS G --
! C100 30067966 CAP MKP SAFE 220NF275VMACX215BOXLEFTBROH G --
C101 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
! C102 30068025 CAP MKT SAFE 1UF 450V K 15DIPLB TOS RoHS G --
C103 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
! C105 30067966 CAP MKP SAFE 220NF275VMACX215BOXLEFTBROH G --
C106 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
! C109 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C112 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
! C113 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C114 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
! C115 30068234 CAP MKP SAFE 100NF 275V M X2AC15BOX ROHS G --
C116 30066377 CAP CER 220PF 1KV K YRN 125C(PULSE) ROHS G --
C117 30000263 CAP SMD 56PF 50V J COG (0805) ROHS G --
! C118 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C120 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
! C121 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
! C122 30068025 CAP MKT SAFE 1UF 450V K 15DIPLB TOS RoHS G --
C123 30000284 CAP SMD 1NF 50V K X7R (0805) ROHS G --
C124 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C129 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C131 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
CAPACITORS
COILS AND FILTERS
