2. Removing of major Parts 46” (Continued)
SPEAKER
(SUBWOOFER)
TO DISPLAY
SUPPLY
[EL]
AC CORD
[RA]
[PD]
[SP]
[PD]
[LV]
[LW]
SPEAKER -L
(TWEETER)
SPEAKER -R
(TWEETER)
[LV]
[LW]
CN2
CN4
CN1
[BL]
[SB]
Main unit
Power unit
