Sharp LC-40LE810E Service Manual

LC-40/46LE810E, LC-40/46LX810E
4 – 7
2. Removing of Speaker-L/R.
1. Remove the 3 lock screws and detach the Stand Cover .
2. Disconnect SP wire.
3. Detach the Speaker-L , Speaker-R .
4. Detach the Insulation Sheet (AC) .
MAIN Unit
[SP]
[SP]
4Speaker-R 3 Speaker-L
2 Stand Cover
1
5
Insulation
Sheet (AC)
