Sharp LC-40LE820UN - Outline; Major Service Parts

LC-40/46/52/60LE820UN
iv
LC-40LE820UN
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB UNIT
OTHER UNIT
IC FOR EXCLUSIVE USE OF THE SERVICE
NOTE: *1 Replace MAIN PWB Units (DKEYMF452FM02) in case of IC8455, IC8401 or IC3302 failure.
*2 TOUCH SENSOR Unit (RUNTKA690WJQZ) reuse will be impossible, once it is stuck on front glass and exfoliates.
Therefore, please exchange of a touch sensor unit in the case of front glass exchange.
SERVICE JIGS
Ref No. Part No. Description
N DKEYMF452FM02 MAIN Unit *1
N DUNTKF493FM01 ICON Unit
N DUNTKF493FM02 LOGO Unit
N DUNTKF494FM01 R/C, LED Unit
N RUNTKA682WJQZ POWER/LED Drive Unit (LC-40LE820UN)
N RUNTKA683WJQZ POWER/LED Drive Unit (LC-46LE820UN)
N RUNTKA693WJQZ POWER/LED Drive Unit (LC-52LE820UN)
N RUNTKA684WJQZ POWER/LED Drive Unit (LC-60LE820UN)
N RUNTKA690WJQZ TOUCH SENSOR Unit *2
N RUNTK4437TPZZ LCD CONTROL Unit (LC-40LE820UN)
N RUNTK4437TPZA LCD CONTROL Unit (LC-46LE820UN)
N RUNTK4437TPZB LCD CONTROL Unit (LC-52LE820UN)
N RUNTK4437TPZC LCD CONTROL Unit (LC-60LE820UN)
N RUNTK4462TPZZ LED PWB Unit (LC-40LE820UN), x4
N RUNTK4461TPZZ LED PWB Unit (LC-46LE820UN), x4
N RUNTK4460TPZZ LED PWB Unit (LC-52LE820UN), x4
N RUNTK4458TPZZ LED PWB Unit (LC-60LE820UN), x4
N RUNTK4459TPZZ LED PWB Unit (LC-60LE820UN), x4
Ref No. Part No. Description
N R1LK400D3LWF0Z 40” LCD Panel Module Unit
N R1LK460D3LWA0Z 46” LCD Panel Module Unit
N R1LK520D3LWA0Z 52” LCD Panel Module Unit
N R1LK600D3LW20Z 60” LCD Panel Module Unit
Ref No. Part No. Description Q'ty
IC509 VHiR24002AS1YS R1EX24002ASAS0A (RGB EDID) 1
IC2002 RH-iXC786WJNHQ R5F364A6NFB (MICON) 1
Ref No. Part No. Description Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pin LCD Control to LCD Panel Unit x2 2
N QCNW-H184WJQZ Connecting Cord L=1000mm 12pin Main to Power Unit (PD) 1
N QCNW-F676WJQZ Connecting Cord L=1000mm 41pin Main to LCD Control (LW) 1
N QCNW-G405WJQZ Connecting Cord L=1000mm 4pin Main to LCD Control (PL) 1
N QCNW-G394WJQZ Connecting Cord L=1000mm 9pin Main to Power (LB) 1
