Sharp LC-40LX630E User Manual

160
LC-32LE63x
LC-40LE63x
LC-46LE63x
12.23.1 LC-32LX63x Mechanical Parts
LC-32L*630
POWER
unit
MAIN
unit
3
c
c
d
b
b
e
d
e
f
f
g
g
a
h
A
15
16
A
B
B
4
5
31
10
36
8
9
18
14
11
13
13
18
1
2
CONTROL
BUTTON
unit
a
A
17
29
30
34
6
h
34
40
19
20
33
33
33
21
22
23
24
25
26
27
VT
33
28
34
35
33
33
33
33
33
33
33
VT
HL
HL
C
C
12
32
33
26
27
33
7

Sharp LC-40LX630E Specifications

General

Response time	6 ms
Display diagonal	40 \
Display brightness	450 cd/m²
Native aspect ratio	16:9
Native refresh rate	100 Hz
LED backlighting type	Edge-LED
Supported video modes	1080p
Display diagonal (metric)	102 cm
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	No
Annual energy consumption	70 kWh
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-T
RMS rated power	10 W
Number of speakers	2
HDMI version	1.4
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Video formats supported	H.264, MPEG4
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.15 W
Power consumption (typical)	48 W

Weight and Dimensions

Depth (with stand)	242 mm
Height (with stand)	630 mm
Weight (with stand)	14700 g
Depth (without stand)	40 mm
Width (without stand)	947 mm
Height (without stand)	560 mm
