Sharp LC-40LX630E User Manual

69
LC-32LE63x
LC-40LE63x
LC-46LE63x
Test setting Digital info Current frequency: 538
QAM modulation: 64-qam Display information is for development purposes
Symbol rate:
Original network ID: 12871
Network ID: 12871
Transport stream ID: 2
Service ID: 3
Hierarchical modulation: 0
Selected video PID: 35
Selected main audio PID: 99
Selected 2nd audio PID: 8191
Install start frequency 000 Install start frequency from “0” MHz
Install end frequency 999 Install end frequency as “999” MHz
Default install frequency
Installation Digital only Select Digital only or Digital + Analogue before
installation
Digital + Analogue
Development file
versions
Development 1 file version Display parameters DISPT5.0.9.29 Display information is for development purposes
Acoustics parameters ACSTS
5.0.6.20
PQ - TV550 1.0.27.22
PQS- Profile set
PQF - Fixed settings
PQU - User styles
Ambilight parameters PRFAM 5.0.5.2
Development 2 file version 12NC one zip software Display information is for development purposes
Initial main software
NVM version Q55x1_0.4.5.0
Flash units software
Temp com file version none
Upload to USB Channel list To upload several settings from the TV to an USB
stick
Personal settings
Option codes
Alignments
Identification data
History list
All (options included)
Download from USB Channel list To download several settings from the USB stick to
the TV
Personal settings
Option codes
Alignments
Identification data
All (options included)
NVM editor Type number see type plate NVM editor; re key-in type number and production
code after SSB replacement
AG code see type plate
Main Menu Sub-menu 1 Sub-menu 2 Sub-menu 3 Description
Alignments (continued)
DISPT5.0.9.7
5.2.6.6
1.0.27.7
(e.g. )“S5551_0.9.16.0”
(Press “OK” to enter)
Production Code (Press “OK” to enter)
Enter the model name, e.g. LC32LE630E (whitout “-”)
Serial Number

Sharp LC-40LX630E Specifications

General

Response time	6 ms
Display diagonal	40 \
Display brightness	450 cd/m²
Native aspect ratio	16:9
Native refresh rate	100 Hz
LED backlighting type	Edge-LED
Supported video modes	1080p
Display diagonal (metric)	102 cm
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	No
Annual energy consumption	70 kWh
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-T
RMS rated power	10 W
Number of speakers	2
HDMI version	1.4
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Video formats supported	H.264, MPEG4
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.15 W
Power consumption (typical)	48 W

Weight and Dimensions

Depth (with stand)	242 mm
Height (with stand)	630 mm
Weight (with stand)	14700 g
Depth (without stand)	40 mm
Width (without stand)	947 mm
Height (without stand)	560 mm
