LC-42D43U
i
LC-42D43U
Service Manual
OUTLINE AND MODIFIED PARTS LIST
OUTLINE
This Service Manual covers the differences from LC-32/37D42U. For other technical information, refer to the LC-32/37D42U (No. S06X9LC32D42U)
Service Manual.
The new model can be identified with the following markings.
• The character is added at the end of the model name on the model label.
• The character is also added at the end of the model name on the number label (barcode label) of the
packing case.
• The serial product numbers (in the 1 th thru 9th digits) are 710802401 and on.
MODIFIED PARTS LIST
Refer to PARTS GUIDE for CABINET PARTS, SUPPLIED ACCESSORIES, PACKING PARTS and SERVICE JIGS.
Ref No. Description LC-32D42U/LC-37D42U LC-42D43U(A) Note
Printed Wiring Board Assemblies
MAIN Unit DUNTKD862FM04 DUNTKE862FM04 No Change
R/C, LED Unit DUNTKD909FM02 DUNTKD909FM02 No Changes
KEY Unit DUNTKD910FM02 DUNTKD910FM02 No Changes
AV-Terminal Unit DUNTKD999FM04 DUNTKD935WE03 Change
POWER Unit RDENCA198WJQZ RDENCA226WJQZ Changes
A
A
MAIN unit change model
A mark on the right side of the model name
