LC-42D43U
3 – 6
2.3. Menu list in process A mode
Page Line Item Explanation
4 TUNER VCHIP TEST (69ch) Execute TUNER TEST
TUNER VCHIP TEST (7ch)
TUNER VCHIP TEST (4ch)
TUNER VCHIP TEST (10ch)
TUNER VCHIP TEST (15ch)
PC Set
Adjust RB to the target xy values.
MG1RXXXX
MG1BXXXX
* XXXX indicates the adjusted values between 0000 and 1023
(4 digit decimal number with zero fill).
* G is fixed.
* The default adjustment value of RGB is the parameter value of
the WBI1 command multiplied by 2.
Adjustment values are set.
OK
Repeat until RGB
become the target
values.
The adjustment value is
reflected in the image.
Writing of adjusted values
MSET0003
Deletion is complete.
OK
Deleting adjustment patterns
MSET0000
Writing is complete.
OK
Start measurement
Completion of adjustment
To Next Page
