LC-42D65U
4 – 1
LC-42D65U
Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Remove the 4 lock screws and detach the Stand.
2. Remove the 4 VESA Hole Covers.
3. Remove the 1 lock screw, 13 lock screws and detach the Rear Cabinet.
3
3
2
1
Front Cabinet
Rear Cabinet
Stand
