LC-42D65U
1 – 1
LC-42D65U
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item Model: LC-42D65U
LCD panel 42" Class (42
1
/
64
"
Diagonal)
Resolution 2,073,600 pixels (1,920 1,080)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 10W 2
Terminals
Rear
INPUT 1 AV in, COMPONENT in
INPUT 2 COMPONENT in, S-VIDEO in
INPUT 4 15-pin mini D-sub female connector, Audio in (Ø 3.5 mm jack)
INPUT 6 HDMI in with HDCP, Audio in (Ø 3.5 mm jack)
INPUT 7 HDMI in with HDCP
INPUT 8 HDMI in with HDCP
INPUT 9 HDMI in with HDCP
ANT/CABLE 75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
AUDIO Audio in (Ø 3.5 mm jack)
DIGITAL AUDIO OUTPUT
Optical Digital audio output 1 (PCM/Dolby Digital)
OUTPUT Audio out
RS-232C 9-pin D-sub male connector
Side
INPUT 3 AV in
INPUT 5 HDMI in with HDCP
SERVICE Software update
OSD language English/French/Spanish
Power Requirement
AC 120 V, 60 Hz (FOR NORTH AMERICA)
AC 110-240 V, 50/60 Hz (FOR OTHERS)
Power Consumption 235 W (0.4 W Standby with AC 120 V)
Weight
TV + stand 55.1 lbs./25.0 kg
TV only 44.0 lbs./20.0 kg
Dimension
*2
(W H D)
TV + stand 40
11
/
64
28
1
/
32
12
13
/
16
inch
TV only 40
11
/
64
25
9
/
16
3
61
/
64
inch
Operating temperature 32°F to 104°F (0°C to 40°C)
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the inside back cover.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
