Sharp LC-42XL2E User Manual

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 3
4. Remove all the connectors from PWBs.
5. Remove the R/C, LED Unit.
LED PWB
Wire "RA"
from OBON
Wire "IL"
from Illumination
Wire "RA"
LED PWB Front side
LED PWB Back side
Pull out Wire "IL","RA" from bottom
1st, Set LED PWB Under LIB
LED PWB
(with wire)
#Set PWB to gide lib surely
Next,Push PWB hooked
Wire "IL"
Wire "RA" to WH
