Sharp LC-42XL2E User Manual

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE186FM01 N R MAIN Unit (LC-42/46/52XL2E/S/RU)
N DUNTKE186FM02 N R MAIN Unit (LC-46/52X20E/S/RU)
N DUNTKE187FM01 N R TERMINAL Unit (LC-42XL2E/S/RU, 46XL2E/S/RU, 52XL2E/S/RU)
N DUNTKE187FM02 N R TERMINAL Unit (LC-46X20E/S/RU, 52X20E/S/RU)
N DUNTKE264FM01 N R R/C, LED Unit
N DUNTKE266FM01 N R KEY Unit
N DUNTKE188FM01 N R MIN IAV Unit
N DUNTKE270FM01 N R ILLUMINATION Unit (LC-42/46/52XL2E/S/RU only)
N RDENCA231WJQZ - N P POWER Unit (Unit Replacement Item)
N RUNTKA311WJQZ - N P AC INLET Unit (Unit Replacement Item)
[2] LCD PANEL AND TUNER (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT
NOT INDEPENDENTLY.)
N R1LK420D3LZ60Y N J 42" Full HD LCD Panel Module (LC-42XL2E/S/RU)
N R1LK460D3LZ60Y FT N J 46" Full HD LCD Panel Module (LC-46XL2E/S/RU)
N R1LK460D3LZ50Y ** N J 46" Full HD LCD Panel Module (LC-46X20E/S/RU)
N R1LK520D3LZ60Y N J 52" Full HD LCD Panel Module (LC-52XL2E/S/RU)
N R1LK520D3LZ50Y N J 52" Full HD LCD Panel Module (LC-52X20E/S/RU)
!
TU7501 RTUDAA014WJQZ AX N P Tuner
[3] DUNTKE186FM01/FM02 (MAIN Unit)
C1112 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1117 VCCCCZ1HH3R0CY AA J Capacitor 30p 50V Ceramic
C1118 VCCCCZ1HH3R0CY AA J Capacitor 30p 50V Ceramic
C1119 VCCCCZ1HH3R0CY AA J Capacitor 30p 50V Ceramic
C1120 VCCCCZ1HH390JY AB J Capacitor 39p 50V Ceramic
C1121 VCCCCZ1HH390JY AB J Capacitor 39p 50V Ceramic
C1122 VCCCCZ1HH390JY AB J Capacitor 39p 50V Ceramic
C1123 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1124 VCCCCZ1HH181JY AB J Capacitor 180p 50V Ceramic
C1125 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C1126 VCCCCZ1HH471JY AA J Capacitor 470p 50V Ceramic
C1128 VCAAPE1CJ686MY AE J Capacitor 68 16V Electrolytic
C1129 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1130 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1137 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1138 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1501 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1502 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1503 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1504 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1505 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1506 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1507 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1508 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1509 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1510 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1511 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1512 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1513 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1514 VCERML1CN106MY AC J Capacitor 10 16V Electrolytic
C1515 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1516 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1517 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1521 VCKYCZ1HB102KY AB J
Capacitor 1000p 50V Ceramic
C1522 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1523 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1524 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1525 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1526 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1531 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1532 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1534 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1538 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1540 VCAAPE0JJ227MY AE J Capacitor 220 6.3V Electrolytic
C1543 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1544 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1545 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1546 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1547 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1548 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1551 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1578 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1579 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1582 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1583 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1586 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1587 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1589 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1591 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1592 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1596 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1597 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1599 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
