Sharp LC-42XL2E - Page 37

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 20
12.Remove the 1 lock screw , and the 12 lock screws . Detach the Chassis Tray and MINI AV Sub Ass’y.
13.Remove the 14 lock screws . and detach the Panel Support Angle.
9
10
10
Wire "LC"
MINI AV SUB ASSY
CHASSIS TRAY
9
11
PNL SUPPORT ANG
LCD MODULE
Wire "LC"
11
