LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 24
20.Remove all the connectors from PWBs.
Wire "VD" to WH
Wire "KM"
Wire "HM"
Wire "LW"
Wire "RA","US","KM","VD" to WH
Wire "HM" to WH
#Shape Wire "US"
like this
Wire "RA","US","KM" to WH
Wire "US"
Wire "VD"
Wire "RA"
#Don't make mistake Wire "VD" and "RA"
Wire "LW"
Wire "HM"
Wire
Wire "US"
Wire
Wire "VD"
Wire
Wire "RA"
Wire "LW"
To Main PWB
To LED PWB
To Main PWB
To LCD Control PWB
Wire "LA1"
Wire "LA1"
#No shape Wire "LA1" to WH
