LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
3 – 7
Page Line Item Description Remarks (adjustment detail, etc.)
26/33 [M V6THE]
1V6 OS THERMO 1 64
2V6 OS THERMO 2 77
3V6 OS THERMO 3 87
4V6 OS THERMO 4 97
5 V6 OS THERMO 5 108
6 V6 OS THERMO 6 119
7 V6 OS THERMO 7 131
27/33 [M V5THE]
1V5 OS THERMO 1 64
2V5 OS THERMO 2 77
3V5 OS THERMO 3 87
4V5 OS THERMO 4 97
5 V5 OS THERMO 5 108
6 V5 OS THERMO 6 119
7 V5 OS THERMO 7 131
28/33 [M BLCTL TEMP]
1BL TEMP1
2BL TEMP2
3BL TDUTY
29/33 [M EEP SET]
1 MONITOR TIME OUT ON Monitor and the main communication time-out setting
2 MONITOR MAX TEMP 43 MONITOR MAX temperature setting
3 MONITOR EEP READ / WRITE WRITE MONITOR EEPROM READ/WRITE Setting/execution
4 MONITOR EEP ADR 0x 0 MONITOR EEPROM arbitrary addressing
5 MONITOR EEP DATA 0x 0 MONITOR EEPROM arbitrary data specification
30/33 [M TEST PATTERN]
1 LCD TEST PATTERN OFF Pattern with built-in LCD controller display
31/33 [MEM CLEAR]
1 KEY LOCK(1217) Enter
2 KOUTEI AREA ALL CLEAR Adjustment value clearness in all areas in process
3 A MODE AREA CLEAR Adjustment value clearness of process A mode
4 BACKUP AREA CLEAR Adjustment value clearness in process backup area
5 B MODE AREA CLEAR Adjustment value clearness of process B mode
6 EXECUTION Clear execution
32/33 [FR REGI]
1 READ/WRITE READ
2 SLAVE ADDRESS SLAVE0
3 REGISTOR ADDRESS 0x 0
0x 0
4 WRITE DATA 0x 0
0x 0
5 READ DATA 0x 0
0x 0
33/33 [ETC]
1 EEP SAVE OFF Writing setting values to EEPROM.
2 EEP RECOVER OFF Reading setting values from EEPROM.
3 MONITOR ERROR CAUSE RESET OFF
4 STANDBY CAUSE RESET OFF Reset stand by cause.
5 MODEL NAME XL2 Model name setting
6 PANEL SIZE 52 Panel size setting.
7 PRODUCT EEP ADR 0x 0
8 PRODUCT EEP DATA 0x 0
