LC-42D64U/46D64U/52D64U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE558FM01 CB N X MAIN Unit
N DUNTKE208FM01 BH N X TERMINAL Unit
N DUNTKE488FM01 BB N X SIDE Unit
N DUNTKE264FM02 AP N X R/C, LED Unit
N DUNTKE266FM02 AG N X KEY Unit
N RDENCA235WJQZ BR N X POWER Unit
N RUNTKA317WJQZ AW N X AC INLET Unit
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
N R1LK420D3LZ50Z EZ N J 42" Wide LCD Panel Module Unit (LC-42D64U)
N R1LK460D3LZ50Z FP N J 46" Wide LCD Panel Module Unit (LC-46D64U)
N R1LK520D3LZ50Z GN N J 52" Wide LCD Panel Module Unit (LC-52D64U)
[3] DUNTKE558FM01 (MAIN Unit)
C1301 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1303 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1308 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1310 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1311 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1312 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1313 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1314 RC-KZA098WJZZY AD J Capacitor, 10 25V Ceramic
C1401 VCCCCZ1HH120JY AB J Capacitor, 12p 50V Ceramic
C1402 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1403 VCKYCZ1AB104KY AB J Capacitor, 0.1 10V Ceramic
C1404 VCCCCZ1HH120JY AB J Capacitor, 12p 50V Ceramic
C1405 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1406 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1407 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1408 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1409 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1411 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1412 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C1414 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1415 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1417 VCKYCZ1EB103KY AA J Capacitor, 0.01 25V Ceramic
C1418 RC-KZA154WJZZY AB J Capacitor, 4.7 16V Ceramic
C1419 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1421 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1422 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1423 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1424 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1425 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1426 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1427 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1428 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1429 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1430 VCKYTV1CB105KY AC J
Capacitor, 1 16V Ceramic
C1431 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1432 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1440 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1441 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1601 VCKYCZ1HB221KY AA J Capacitor, 220p 50V Ceramic
C1602 VCKYCZ1HB221KY AA J Capacitor, 220p 50V Ceramic
C1603 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1604 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1605 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1606 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1607 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1609 VCKYCZ1EB103KY AA J Capacitor, 0.01 25V Ceramic
C1611 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1612 VCKYCZ1EB103KY AA J Capacitor, 0.01 25V Ceramic
C1619 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1620 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1621 RC-KZA520WJQZY AA J Capacitor, 1 10V Ceramic
C1623 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1625 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1626 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1627 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1628 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1629 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1630 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1631 RC-KZA520WJQZY AA J Capacitor, 1 10V Ceramic
C1632 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1633 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1635 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1636 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1637 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1638 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1639 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1640 VCKYCZ1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1641
VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1642 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
