PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-42D64U/46D64U/52D64U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL (NOTE: THE PARTS
HERE SHOWN ARE SUPPLIED AS
AN ASSEMBLY BUT NOT
INDEPENDENTLY.)
[3] DUNTKE558FM01 (MAIN Unit)
[4] DUNTKE208FM01
(TERMINAL Unit)
[5] DUNTKE488FM01 (SIDE Unit)
[6] DUNTKE264FM02 (R/C, LED Unit)
[7] DUNTKE266FM02 (KEY Unit)
[8] NOTE (Conductive cloth tape)
[9] NOTE (Temperature-proof cover)
[10] CABINET AND MECHANICAL
PARTS (LC-42D64U)
[11] CABINET AND MECHANICAL
PARTS (LC-46D64U)
[12] CABINET AND MECHANICAL
PARTS (LC-52D64U)
[13] SUPPLIED ACCESSORIES
[14] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-42D64U)
[15] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-46D64U)
[16] PACKING PARTS
(NOT REPLACEMENT ITEM)
(LC-52D64U)
[17] SERVICE JIG
(USE FOR SERVICING)
CONTENTS
No. SX7B5LC42D64U
MODELS
LC-42D64U
LC-46D64U
LC-52D64U
LCD COLOR TELEVISION
