LC-42D64U/46D64U/52D64U
2 – 10
6. Remove the Speaker-L and R.
7. Remove the 5 lock screws, 2 lock screws and detach the Tray Chassis and Terminal Bottom Angle.
Tray Chassis
Terminal Bottom Angle
Speaker-R
Speaker-L
7
7
6
6
