2.16. IC8101 (RH-iXC011WJQZQ)
2.16.1 Pin Connections and short description
Ref No. Pin Name I/O Pin Function
DAC Interface
AD2 VDDZ_DAC — Digital power for DAC (+3.3V).
AD3 VSSZ_DAC — Digital ground for DAC.
AD1 DAC_VS I/O DAC vsync.
AE1 DAC_HS I/O DAC hsync.
AE2 DAC_CLK I/O DAC clock
AE4 DAC_DE I/O DAC DE
AE3 DAC_FLD I/O DAC field.
AA5 AVSS51 — Analog ground for DAC (for bias circuit).
AB5 COMP — Bias for DAC coupling capacitor.
AB4 IRSET I Bias for DAC current source.
AB3 CVBS_B I DAC blue or PB (Not used).
AB2 ADVSS2 — Analog ground for DAC (for DAC’s AVSS52).
AB1 ADVDD2 — Analog power for DAC (+3.3V).
AC1 C_G I DAC green or Y (Not used).
AC2 AVSS50 — Digital ground for DAC.
AC3 AVDD50 — Analog power for DAC (+3.3V).
AC4 Y_R I DAC red or PR (Not used).
AC5 ADVSS2 — Analog ground for DAC (for DAC’s AVSS52).
AD5 ADVDD2 — Analog power for DAC (+3.3V).
AD4 VM I DAC VM
ADC Interface
N2 AVDD — ADC power +3.3V.
N3 VIN1 I VRADC INPUT1 (Not used)
N4 VIN2 I VRADC INPUT2 (Not used)
N5 AVSS — ADC ground.
USB Interface
R3 USB_PPON_PP O USB Power on control.
R2 USB_OC_PP I USB over current control.
P5 VDDA — Analog core +3.3V supply.
P4 DN O Negative output channel.
P3 DP O Positive output control.
P2 VSSA — Analog core ground.
P1 RREFEXT — External resistor connection for current reference.
R5 VSSP — PLL ground pin Double Bond.
R4 VDDP — PLL +1.2V supply Double Bond.
LVDS Interface
AJ5 LVDS_VSSP — LVDS PLL Ground.
AJ3 LVDS_VDDP — LVDS PLL Power supply (+3.3V).
AK5 LVDS_VSSO — LVDS Output buffer VSS (Long pad)
AK4 LVDS_VDDO — LVDS Output buffer VDD (+3.3V).
AK1 TF2P O LVDS Positive Output. (Not used)
AK2 TF2M O LVDS Negative Output. (Not used)
AL1 TE2P O LVDS Positive Output. (Not used)
AL2 TE2M O LVDS Negative Output. (Not used)
AM1 TD2P O LVDS Positive Output. (Not used)
AM2 TD2M O LVDS Negative Output. (Not used)
AN1 TCLK2P O LVDS Positive clock Output. (Not used)
AN2 TCLK2M O LVDS Negative clock Output. (Not used)
AP1 TC2P O LVDS Positive Output. (Not used)
AP2 TC2M O LVDS Negative Output. (Not used)
AM4 LVDS_VDDO — LVDS Output buffer VDD (+3.3V).
AP3 TB2P O LVDS Positive Output. (Not used)
AN3 TB2M O LVDS Negative Output. (Not used)
AP4 TA2P O LVDS Positive Output. (Not used)
AN4 TA2M O LVDS Negative Output. (Not used)
AJ6 LVDS_VSSO — LVDS Output buffer VSS.
AP5 TF1P O LVDS Positive Output. (Not used)
AN5 TF1M O LVDS Negative Output. (Not used)
AP6 TE1P O LVDS Positive Output. (Not used)
AN6 TE1M O LVDS Negative Output. (Not used)
