LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 43
9. Remove all the connectors from PWBs.
Wire "LC", "LA2", "LB" to WH
Wire "LC" to WH
Wire "LC", "LA1" to WH
FFC "HM" to WH
Wire "KM", "VD", "US" to WH
Wire "KM" to Hook
Wire "KM" to WH
Wire "RA", "KM", "VD", "US" to
Wire "SP" to WH
Wire "LA1"
Wire "LA2"
Wire "LB"
FFC "HM"
Wire "US"
Wire "VD"
Wire "KM"
Wire "FR"
Wire "LW"
