LC-46D82U/LC-52D82U
2 – 7
15.Remove the 8 lock screws and detach the FRC PWB Angle.
16.Remove the 4 lock screws and detach the Panel Module Ass’y.
12
FRC_UNIT
FRC_PWB_ANG
LCDCON-FRC(11P) WIRE
IC6001 COOL
㵘㵘㵘㵘㵘䋨10x10x2)
IC5801 COOLL
㵘㵘㵘㵘㵘䋨20x20x2)
FRC PWB SET ANG
SILICON GREASE
SILICON GREASE
*CAUTION
Designation in the installation
direction
(9) QPWBHE107WJQZ ×2
FRC-LCDCON(FPC)
(Both side)
FRC side
䋨㪇㪇㪌㪎㪉㪉䋩
㪧㪸㫉㫋㩷㫀㫅㪻㫀㪺㪸㫋㫀㫆㫅
LCD side
12
12
13
Panel Module Ass’y is fitted to the
bottom right side.
INSIDE
PANEL MODULE ASS’Y
INSIDE
PANEL BACK Side
INSIDE
INSIDE
13
13
13
