LC-46D82U/LC-52D82U
2 – 9
20.Remove all the connectors from PWBs.
21.Remove the 7 lock screws , and , and detach the AV Terminal Angle Ass’y.
LV
LB
SP
SAFCMA
PH
PD
A
LA
PH
PD
KM
RA
LP
㩷
SHAPE(LB) x2
SHAPE(LB) x3
SHAPE(KM) x2
SHAPE (RA.SP)
NG AREAOK AREA
SP
NG AREAOK AREA
SP
TURN
TRN
Base line of Shape SP Wire
(The center of socket)
*CAUTION
Wire-tape tab control specification
(Prevention of a wound with the shielding case)
Tape Position is between WH and WH.
CAUTION
The LB wire is under the
PD wire and PH wire.
CAUTION
Shape without play.
(KM Wire)
CAUTION
Straight line(Don't make a wire have looseness.)
SHAPE (PH,PD)
17
18
19
+
㩷㩷㪫㪜㪩㪤㪄㪘㪥㪞㪄㪣㪦㪥㪞㩷㪘㪪㪪㵭㪰
㩷㩿㪧㫉㪼㫇㪸㫉㪼㪻㪀
18
17
19
