LC-46D82U/LC-52D82U
2 – 21
20.Remove the 7 lock screws and detach the Power unit.
21.Remove the 4 lock screws and detach the Terminal unit.
19
㵘㵘
POWER UNIT
Power unit is fitted to the
bottom left side.
Fit
POWER UNIT
Fit
POWER UNIT
Insert
POWER UNIT
Fit
POWER UNIT
The screw is
unnecessary.
(×3)
19
20
PREPARED TERMINAL UNIT
㵘
Base line
(Side of㵘Tray)
Base line
(Edge of ಲ)
TAPE
20
