Is there the audio signal input at pins (5) (L) and (3) (R) of IC2701 (STEREO_AMP)?
NO
Check the line between P2704 and
IC2701, and their peripheral circuits
(AMP_MUTE line).
YES
Is there the audio output from IC2701 as specified?
NO
Check IC2701 and its peripheral circuit.
YES
Check the connector (P2703), speakers and their peripheral circuits.
To Next Page
