LC-46D82U/LC-52D82U
5 – 5
79 BE5_FO O Blue Data Signal Output (EVEN) R7
80 BE2_FO O Blue Data Signal Output (EVEN) R8
81 GE8_FO O Green Data Signal Output (EVEN) R9
82 GE4_FO O Green Data Signal Output (EVEN) R10
83 GE0_FO O Green Data Signal Output (EVEN) R11
84 RE7_FO O Red Data Signal Output (EVEN) R12
85 RE5_FO O Red Data Signal Output (EVEN) R13
86 RE3_FO O Red Data Signal Output (EVEN) R14
87 GND - Ground R15
88 BO9_FO O Blue Data Signal Output (ODD) P15
89 BO5_FO O Blue Data Signal Output (ODD) N15
90 BO2_FO O Blue Data Signal Output (ODD) M15
91 GO7_FO O Green Data Signal Output (ODD) L15
92 GO4_FO O Green Data Signal Output (ODD) K15
93 CLK6 - Pin for Clock J15
94 CLK5 - Pin for Clock H15
95 RO6_FO O Red Data Signal Output (ODD) G15
96 RO4_FO O Red Data Signal Output (ODD) F15
97 Reserved E15
98 IHS_FO O Horizontal Sync Signal Input D15
99 Reserved C15
100 GND - Ground B15
101 RE4_FI I Red Data Signal Input (EVEN) B14
102 RE7_FI I Red Data Signal Input (EVEN) B13
103 GE4_FI I Green Data Signal Input (EVEN) B12
104 GE8_FI I Green Data Signal Input (EVEN) B11
105 BE6_FI I Blue Data Signal Input (EVEN) B10
106 BE9_FI I Blue Data Signal Input (EVEN) B9
107 Reserved B8
108 GE2_FI I Green Data Signal Input (EVEN) B7
109 RE1_FI I Red Data Signal Input (EVEN) B6
110 BE0_FI I Blue Data Signal Input (EVEN) B5
111 LVDS_SEL I LVDS Mapping Switching Signal(0:National Semiconductor, 1:THine) B4
112 SCL_FI I SCL Signal Input for I2C B3
113 NC - C3
114 RO9_FI I Red Data Signal Input (ODD) D3
115 GO6_FI I Green Data Signal Input (ODD) E3
116 NC - F3
117 VCCIO1 - Power Supply 3.3V G3
118 GND - Ground H3
119 GND - Ground J3
120 VCCIO1 - Power Supply 3.3V K3
121 RO3_FI I Red Data Signal Input (ODD) L3
122 BO3_FI I Blue Data Signal Input (ODD) M3
123 Reserved N3
124 BO1_FI I Blue Data Signal Input (ODD) P3
125 DEIO_FI I Data Enable Signal Output (ODD) P4
126 BE9_FO O Blue Data Signal Output (EVEN) P5
127 Reserved P6
128 VCCIO4 - Power Supply 3.3V P7
129 GND - Ground P8
130 GND - Ground P9
131 VCCIO4 - Power Supply 3.3V P10
132 GE1_FO O Green Data Signal Output (EVEN) P11
133 RE8_FO O Red Data Signal Output (EVEN) P12
134 RE1_FO O Red Data Signal Output (EVEN) P13
135 RE0_FO O Red Data Signal Output (EVEN) P14
136 NC - N14
137 NC - M14
138 GO8_FO O Green Data Signal Output (ODD) L14
139 VCCIO3 - Power Supply 3.3V K14
140 GND - Ground J14
141 GND - Ground H14
142 VCCIO3 - Power Supply 3.3V G14
143 Reserved F14
