Sharp LC-52LE640U - The Location Putting on the Heat Measure Sheet; MAIN PWB Unit; LCD Control Unit

LC-52/60/70LE640U,C6400U (1st Edition)
4 – 19
[4] The location putting on the heat measure sheet
1. MAIN PWB Unit
• LC-60LE640U/C6400U
• LC-70LE640U/6400U
2. LCD Control Unit (LC-60LE640U/C6400U)
Put 䇼PSPAZC805WJKZ䇽 along these
ruled lines.
PSPAZC741WJKZ
835
PSPA Z C8 5 4WJKZ
TCON CPU COOLER
