Sharp LC-52LE640U

LC-52/60/70LE640U,C6400U (1st Edition)
4 – 6
5. Removing of R/C OPC Unit, ICON Unit, WiFi Unit.
1. Detach the R/C OPC Unit .
2. Disconnect the RA wire.
3. Remove the 1 lock screw and detach the ICON Unit .
4. Disconnect the CI wire.
5. Detach the WiFi Unit .
6. Disconnect the UB wire.
Front Cabinet Ass'y
2
[CI]
3ICON Unit
[UB]
4 WiFi
Unit
[RA]
1R/C OPC Unit
