Sharp LC-52LE640U

LC-52/60/70LE640U,C6400U (1st Edition)
4 – 22
State where the main PWB and shielded case are assembled
The following is a drawing mounting the main PWB Ass’y on the backlight chassis. (The parts indicated by -> are the access holes for confirmation.)
(Main PWB Ass’y => State where the shielded case and RF terminal angle are mounted on the main PWB)
Access hole
Access hole
