Sharp LC-52LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
4 – 10
9. Removing of Bezel Ass’y, Panel Chassis Ass’y, Lens Sheet, Diffusion Plate, Back Light Chassis and LCD
Control Unit (40 inch models).
NOTE: A clean booth is required for repair of the component units and/ or parts (LCD Panel HIRAKI, LED PWB etc.) inside the LCD panel module
unit.
1. Remove the 14 lock screws ,12 lock screws and detach the Bezel Ass’y .
2. Remove the 4 Clip and detach the 40” LCD Panel HIRAKI Unit and Panel Chassis Ass’y .
3. Detach the DBEF Sheet and Lens Sheet and Diffusion Plate .
4. Remove the 21 Push Rivets and 8 Support Pins and detach the Reflection Sheet .
5. Remove the 54 Rivets .
6. Remove the 9 Terminators and 18 connections and detach the 10 LED6 PWB1 Units and 8 LED6 PWB2 Units .
7. Detach the 5 LED5 PWB1 Units and 4 LED5 PWB2 Units .
8. Disconnect the connecting cords from the 9 connectors of the LED5 PWB1/2 Unit.
9. Detach the Back Light Chassis .
10.Detach the 2 Connecting Cord and 2 Ferrite Core .
11.Remove the 6 lock screws and detach the LCD Control Unit
䎳䏄䏑䏈䏏䎃䎃䎦䏋䏄䏖䏖䏌䏖䎃
䎤䏖䏖䎊䏜
䎔
䎕
䎗
䎖
䎘
䎙
䎛
䎜
䎔䎓
䎔䎔
䎔䎕
䎔䎛
䎔䎚
䎔䎘
䎔䎙
䎔䎗
䎔䎗
䎔䎘
䎔䎖
䎔䎙
䎕䎓
䎕䎔
䎕䎕
䎗䎓䎅䎃䎯䎦䎧
䎳䏄䏑䏈䏏䎃䎃
䎫䎬䎵䎤䎮䎬䎃 䎸䏑䏌䏗
䎥䏈䏝䏈䏏䎃䎃䎤䏖䏖䎊䏜
䎯䏈䏑䏖䎃䎶䏋䏈䏈䏗
䎧䏌䏉䏉䏘䏖䏌䏒䏑䎃䎳䏏䏄䏗䏈
䎚
䎧䎥䎨䎩䎃䎶䏋䏈䏈䏗
䎥䏄䏆䏎䎃䎯䏌䏊䏋䏗䎃
䎦䏋䏄䏖䏖䏌䏖
䎩䏈䏕䏕䏌䏗䏈
䎦䏒䏕䏈
䎦䏒䏑䏑䏈䏆䏗䏌䏑䏊䎃䎦䏒䏕䏇
䎯䎦䎧䎃䎦䏒䏑䏗䏕䏒䏏䎃
䎃䎸䏑䏌䏗
䎦䏏䏌䏓
䎵䏈䏉䏏䏈䏆䏗䏌䏒䏑䎃䎶䏋䏈䏈䏗
䎶䏘䏓䏓䏒䏕䏗䎃䎳䏌䏑
䎳䏘䏖䏋䎃䎵䏌䏙䏈䏗
䎔䎜
䎕䎗
䎕䎖

Sharp LC-52LE700E Specifications

General

Display diagonal	52 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	1320 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	176 °
Power requirements	AC 220-240 V / 50 Hz
RS-232 ports	1
HDMI ports quantity	4
SCART ports quantity	2
Component video (YPbPr/YCbCr) in	3
Product color	Black
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (without stand)	95 mm
Width (without stand)	1238 mm
Height (without stand)	765 mm
Weight (without stand)	27600 g
