[7] CABINET AND MECHANICAL PARTS (LC-70LE755U/757U/857U/C7500U)
1 CCABBC195WJ32 N X Rear Cabinet Ass'y
1-1 Not Available - N - Rear Cabinet
1-2 HiNDPE840WJSA N X Terminal Label (Side)
1-3 HiNDPE841WJSA N X Terminal Label (Bottom)
1-4 LHLDWA318WJKZ AD J Cable Tie
1-5 PSPAHB013WJZZ X Himeron
1-6 PSPAHB356WJZZ X Himeron
1-7 PSPAHC330WJZZ X Himeron
2 CCOVAE586WJ33 N X Front Cover Ass'y (LC-70LE755U/757U/C7500U)
2 CCOVAE586WJ34 N X Front Cover Ass'y (LC-70LE857U)
2-1 Not Available - - Center ICON Cover
2-2 Not Available - N - Front Cover
2-3 HDECQB800WJ3A X LED Decoration
2-4 HDECSA106WJSB N X Shine Trim
2-5 LHLDWA289WJKZ AC J Wire Holder
3 CCOVAE589WJ31 N X Bottom Cover Ass'y
3-1 Not Available - N - Bottom Cover
3-2 PSPAHB013WJZZ X Himeron
3-3 PSPAHB468WJZZ X Himeron
4 CCOVAE513WJ31 N X KEY Button Cover Ass'y
4-1 Not Available - N - KEY Button Cover
4-2 HiNDPE573WJSA X Key Label
4-3 JBTN-A984WJ3A N X Key Button
5 GCOVAE530WJ3A N X Decoration Cover (Rear)
6 GCOVAE555WJ3A N X AC Cord Cover
7 HiNDPE821WJZZ N X Energy Guide Label
8 HiNDPE830WJSA N X Model Label (LC-70LE857U)
8 HiNDPE833WJSA N X Model Label (LC-70LE757U)
8 HiNDPE836WJSA N X Model Label (LC-70C7500U)
8 HiNDPE866WJSA N X Model Label (LC-70LE755U)
9 LX-BZA202WJF8 AA J Screw, x28
!
10 QACCDA084WJPZ X AC Cord
11 QCNW-M373WJQZ X Connecting Cord (SP)
12 QCNW-M544WJZZ X Connecting Cord (UB)
13 QCNW-N247WJZZ N X Connecting Cord (RC)
14 QCNW-N302WJZZ N X Connecting Cord (BT) (LC-70LE755U/757U/857U)
15 RSP-ZA572WJZZ AT J Speaker (L/R)
16 RSP-ZA575WJZZ BB J Speaker (Woofer)
17 TLABNB037WJZZ X Serial Label (Back)
18 TLABNE225WJZZ N X Serial Label (Side)
19 XBPS830P06WS0 AA J Screw, x69
20 XEBS830P12000 AA J Screw ,x12
21 CANGKD762WJ31 N X BL Support Angle Ass'y (Bottom)
22 CHLDZB969WJ31 N X P Chassis Unit (Top-L)
23 CHLDZB970WJ31 N X P Chassis Unit (Top-R)
24 CHLDZB971WJ31 N X P Chassis Unit (BottoM-L)
25 CHLDZB972WJ31 N X P Chassis Unit (Bottom-R)
26 CHLDZB973WJ31 N X P Chassis Unit (L)
27 CHLDZB974WJ31 N X P Chassis Unit (R)
28 CANGKD506WJ31 N X VESA Anble Ass'y, x4
29 CANGKD761WJ31 N X Suppor Angle Ass'y (Top)
30 CCHSMA676WJ36 N X BL Chassis Unit Ass'y
31 CHLDZB982WJ31 N X S-PWB Holder Ass'y, x4
32 HDECPA091WJZZ X Decoration Sheet (Bottom)
33 HiNDPE839WJSA X Decoration Sheet (Side)
34 LANGKD145WJFW X Terminal Angle (Side)
35 LANGKD146WJFW X Terminal Angle (Bottom)
36 LANGKD759WJ3W N X Stand Angle (Side), x2
37 LHLDWA289WJKZ AC J Wire Holder
38 LX-BZA207WJF7 AA J Screw, x20
39 LX-LZ0003TPZZ AC N J Rivet, x20
40 PSPAZC690WJZZ AF J Gasket
41 PSPAZC691WJZZ AE J Gasket
42 PSPAZD031WJKZ N X Cooler, x2
43 QCNW-M534WJZZ X
Connecting Cord (SB)
44 Q
CNW-N075WJQZ AM N J Connecting Cord (L1)
45 QCNW-N076WJQZ AN N J Connecting Cord (L2)
46 QCNW-N190WJQZ N X Connecting Cord (FFC 80p), x2
47 QCNW-N191WJQZ N X Connecting Cord (FFC 64p), x2
48 QCNW-N241WJZZ N X Connecting Cord (LV)
49 QCNW-N254WJZZ N X Connecting Cord (PD)
50 RCORFA061WJZZ AG J Ferrite Core, x4
52 CWAKMA035WJ03 N X Aluminum Frame Ass'y (Top)
53 CWAKMA036WJ03 N X Aluminum Frame Ass'y (Bottom)
54 CWAKMA037WJ03 N X Aluminum Frame Ass'y (Left)
55 CWAKMA038WJ03 N X AluminumFrame Ass'y (Right)
56 LANGKD774WJFW AE N J Corner Angle, x4
57 LX-BZA505WJF8 N X Screw, x16
58 TLABZD612WJZZ N X License Label
59 TLABZD636WJSA N X 3D Quattron Label
60 PGiDMA066WJZZ BT N J LGP
61 PMiR-A329WJ3A N X Reflector
62 PSHEPB250WJ3A N X Diffuser
63 PSHEPB251WJN1 N X Lens Sheet
